ASTM Titanium Clad Copper Bar Electroplating
- Product Numbers：2015621884
INTRODUCTION:
Specifications
Ti and non ferrous metal clad plate
explosive method
stainless steel thickness >5mm
non ferrous metal thickness>2mm
Specifications
1.Standards:GB/T12769-2003 2.Coat:Ti,Ni,Zr,Stainless Steel 316L, etc. 3.Base:Cu(T2,TU2),AL,etc.
stainless steel clad copper rods
Standards:GB/T12769-2003
Coat:Ti,Ni,Zr,Stainless Steel 316L, etc.
Base:Cu(T2,TU2),AL,etc.
Shape/Size(mm)
Round:φ(2~80)×(0.5~3.0)
Barrel:φ(25,27,29,32,34)×14×(1.0~2.0)
Square:(10~40)5
Flat:W(10~100)×H(10~30)
Radius Transition:(3~5)
We can,to meet your desire, produce clad bars of different shapes (round,barrel, square,flat),and bend
Our products are widely used in electron, plating, petrol-chemical and chemical industry
Our products are widely used in electron, plating, petrol-chemical and chemical industry, energy source projects, coking, papermaking, saltmaking, ocean projects, wet metallurgy, surface treatment, pharmacy and medical treatment, electrodemaking, coating film etc.
| Compound material product size table | |||||||||||||
| implement national standard: GB/T12769-2003 ASTM | |||||||||||||
| Technology:rolled +stretch | |||||||||||||
| definition | section shape and size(mm) | add material | add material | Substrate material | |||||||||
| layer thickness | |||||||||||||
| square | length(20-40) r(3-8) | 0.5-2.0 | Ti,Zr,Ni,Stainless steel | T2,TU2,AL,etc | |||||||||
| rectangle | length(30-100)width(10-30)r(3-5) | 0.5-2.0 | |||||||||||
| drum | Dia(25,27,29,32,34)*14 | 0.5-2.0 | |||||||||||
| round | Dia(8-50) | 0.5-2.0 | |||||||||||
| wire material | Dia(2.0-8.0) | 0.5-2.0 | |||||||||||
| Application: | Electroplating, electrolysis, wet metallurgy,, petroleum chemical industry, | ||||||||||||
| Energy engineering, ocean engineering,Surface treatment, electrode manufacturing | |||||||||||||
| Advantage: 1.Double metal composite bars production new technology patent certificate | |||||||||||||
| 2.Corrosion resistance, strong conductive | |||||||||||||
